7" Colored Touch LCD
A measurement data and various functional program appear in color on a high clear and precise 7 inch Touch Wide LCD screen.
Comfort and Easy Operation
Mechanically, the main body moves smoothly right to left and forward to backward by an improved design for a base sliding structure.
Communication interface
A data communication is available among the related diagnostic devices by RS-232 and USB.
Embedded Printer
Convenient paper provision and paper replace-ment with a minimized printer problem.
Convenient User Menu Setting
The operator may alter set-up easily and faster.
Outstanding Features
-Convenient S/W Update
S/W update could be done by USB memory easily and conveniently.
-Support for many languages
It serves many languages, basically 10 languages.(English, Spanish, Chinese, Japanese, German, French, Italian, Portuguese, Russian and Korean)
SPECIFICATIONS
Ref. | Vertex Distance (D) | 0, 10, 12, 13.5, 15 mm |
Sphere(SPH) | - 25.00 ~ + 22.00 d (0.12, 0.25 d) | |
Cylinder(CYL) | 0.00 ~ +/- 10.00 d (0.12, 0.25d ) | |
Axis | 1 ~ 180° | |
Cylinder Form | -, +, +/- | |
Pupil Distance | 10 ~ 85 mm | |
Min. Pupil Dia. | ø 2.0 mm | |
Ker. | Radius of Curvature | 5.0 ~ 10.2 mm |
Corneal Power | 33.00 ~ 67.50 d | |
Corneal Astigmatism | 0.00 ~ -15.00 d (0.05/0.12/0.25 d) | |
Axis | 1 ~ 180° | |
Corneal Dia. | 2.0 ~ 12.0 mm | |
Other | Internal Printer | Thermal Printer |
Display | 7.0 inch TFC Color LCD Monitor, Touch | |
Power Supply | AC 100 ~ 240 V, 50/60 Hz, 60-90VA | |
Dim./Weight | 248(W) x 476(D) x 473(H) mm / 21 Kg |
